Pentagonal Prism: length: 44.9mm, width: 20.6mm, height: 19.16mm, coating: T>95%@8-12um

Factory Standard

  • Material: BK7 Grade A optical glass, Corning Fused Silica 7980,  JGS1, JGS2
  • Clear Aperture: >95%
  • Dimension Tolerance: +/-0.1mm
  • Angle Tolerance: <5 arc minutes
  • Flatness: l/4 l @ 632.8 nm
  • Surface Quality: 60-40 scratch and dig
  • Coating: On request

Contact us for manufacturing limit or custom specifications.
